The Syvecs Suzuki Jimny JB74 plug in ecu brings a new level of engine management control to the Suzuki Jimny range with a complete replacement Engine Control Module.
Supports both the manual and automatic transmission models.
The Syvecs Plug in kit comes complete with:
-NTK Lambda Sensor
-NTK Loom
-4Bar Map Sensor
-Air Charge Temperature Sensor
By simply plugging in the kit, a whole new level of control is available which allows turbo and supercharger installations to be safely managed and controlled.
Syvecs Jimny Features:
- Flat Shift/GearCut On Manual Transmission. Allowing Full throttle shifts
- Rev matching on downshift with manual transmission
- Support for automatic transmission with monitoring of line pressure and custom torque reductions.
- Flex Fuel control.
- Fully functional with every other module on the Car.
- 8 Injector support
- Forced induction support, requires External Map sensor and Air Charge Temp sensor
- Closed loop Lambda control using supplied NTK Lambda
- DBW support with cruise control (Option only if the correct parts are fitted)
- Rolling antilag / pit lane limiter strategies, great for building boost on a roll.
- Adjustable traction control strategies based on lateral G and individual wheel speed monitoring.
- Adjustable launch control.
- Limp Protection strategies
- 12 switchable maps with the ability to select desired engine map, boost level, traction and launch control levels through optional rotary switch
- Individual Cylinder Knock control
- Live tuning of every aspect of the engine’s calibration.
- Fully adjustable closed loop boost control with launch level adjustments and trims for turbo speed, air charge, engine coolant temp, exhaust gas temps etc..
- Built in data logging using a market leading analysis software of up to 8 hours, with data rates at up to 1000hz.
- Anti-theft and valet modes.
- Super fast connection via RJ45 Ethernet port for live tuning anywhere in the world or even remotely if on track if connected to one of our Wifi modules.
- Configurable engine safety trips on all important parameters like oil temperature, oil pressure.
- Fuel pump control of both main, and sub pumps, as well as relative fuel pressure monitoring and limiting in the event of fuel pressure dropping on boost.
- Run up to 7bar map sensors.
- Control high or low impendence injectors.
- Ability to fit any type of external sensor to monitor and trigger safety trips from anything from crank case pressure to damper position.
- Ability to use any size DBW throttle body e.g. Chevrolet LS7.
- Wet and Dry – Wet and dry nitrous control with ability to drive solenoids directly and control n20 heaters via pressure monitoring.
- Ability to control any external vehicle features based on sensor inputs e.g. Adjustable rear wing linked to G force or exhaust control valves.
- Connect any race series dash or even one of our Syvecs edition SDM display units.
- View any input live with built in scope up to 1000hz.
And much, much more!
