The biggest feature of this "FULL monoblock caliper" is its capless design, which was developed without any compromises in structure, performance, and durability.
The capless full mono body is manufactured using an ``angle head processing machine''. By adopting this method, it is possible to reduce the number of rubber parts, reduce liquid loss, and design a highly rigid and lightweight caliper.
The adoption of a pad spring reduces rattle noise, and the ultra-thin piston and large-diameter dust boot meet the required specifications for both street and circuit use.
The original brake discs can be used as is, and the brake pads are specially designed for full monocoques and are made of abrasive materials that can be used on both streets and winding roads.
FULL monoblock caliper set
2.9kg (Std 3.15kg)
Material: High-strength aluminum casting
Structure: High-strength one-piece monocoque structure
Piston size: 36.12φ x 4
Rotor diameter: 231φ
*The following full monocoque dedicated brake pads are required separately. .
Product name: BRAKE PAD (FRONT), MBK For MONOCOQUE
Product number: 45022-MBK-000 List
price: 22,000 yen (excluding tax)
Note) The following models are not applicable due to the small diameter of the brake disc. Please check your vehicle identification number.
2012-2013 model
JG1-1000001-1081713
JG2-1000001-1012737
