TechSpec Overall Height (in): 21.49
TechSpec Overall Length (in): 29.41
TechSpec Overall Width (ins): 3.99
TechSpec Core Length (in): 28
TechSpec Core Height (in): 15.75
TechSpec Fluid Capacity (gal): 0.978
TechSpec Rows: 2
TechSpec Inlet (in): 1.65
TechSpec Outlet (in): 1.65
TechSpec Core Thickness (in): 1.42
TechSpec Drain Plug Thread Size: M12x1.5
TechSpec Material: 6061-Aluminum
TechSpec Applications: 2022+ Subaru WRX H4 2.4L Turbo
TechSpec Engine Codes: FA24DIT
TechSpec Chassis Codes: VB
TechSpec Includes: (1) Mishimoto Performance Aluminum Radiator--(1) M12x1.5 Slotted Drain Plug--(1) Mishimoto Radiator Cap--Mishimoto Lifetime Warranty
Features:Direct fit for 2022+ Subaru WRX
32 percent increase in core volume over stock for improved cooling efficiency
50 percent greater fin surface area for improved heat transfer
Two-row core balances optimal flow with cooling performance
Precision TIG-welded end tanks resist vibration and impacts on the street, gravel, or dirt
36mm-thick core with louvered fins makes the most of air moving through the grille
Slotted drain plug makes services mess-free
Mishimoto Lifetime Warranty
Install Difficulty: 3
The Subaru WRX has a rally pedigree unlike any other mass-market vehicle. When you step into your 2022+ WRX, you're stepping into 30 years of hard-earned lessons in building a performance car that's at home on any surface. But going from racing to commuting comes with some sacrifices, especially in the cooling department. While Subaru's rally cars get top-of-the-line cooling systems built for going all-out through miles of forest, gravel, and tarmac, the WRX gets the accountants' choice of plastic end tanks and loosely packed core. With this Mishimoto performance aluminum radiator, you can take your WRX closer to its rally roots and push it to its limits.----Our radiator features aluminum end tanks that are precision TIG-welded to withstand the vibrations and impacts that rally, track, or everyday driving throw at it. To help keep your FA24 boxer engine cool for miles of wide-open-throttle, we've sandwiched a two-row, 36 mm-thick core between those end tanks. This core features densely packed and louvered fins that effectively circulate air throughout the core for maximum heat transfer. The larger core also translates to a 32% increase in core volume, meaning our radiator can pull more heat out of more coolant, for more efficient cooling. A slotted drain plug helps direct coolant into your drain pan, instead of onto the floor during service. Like all Mishimoto radiators, this 2022+ Subaru WRX performance aluminum radiator is backed by our Mishimoto Lifetime Warranty.
