TechSpec Overall Height (in): 32.4
TechSpec Overall Length (in): 15.1
TechSpec Overall Width (ins): 5.9
TechSpec Core Length (in): 29.4
TechSpec Core Height (in): 15.1
TechSpec Rows: 2
TechSpec Core Thickness (in): 2.2
TechSpec Drain Plug Thread Size: M12 x 1.5
TechSpec Material: Aluminum
TechSpec Applications: 2008-2009 Pontiac G8 V8
TechSpec Engine Codes: L98--L76--L77
TechSpec Chassis Codes: Zeta
Note: This radiator has not been tested on 2009.5 or GXP models.
TechSpec Includes: Aluminum Radiator-- Radiator Cap-- Magnetic Drain Plug--Mishimoto Lifetime Warranty
Features:Direct fit for the 2008-2009 Pontiac G8
39-percent increase in core volume
All-aluminum construction including durable, TIG-welded end tanks
Features a two-row, 56mm-thick core for maximum cooling
Provides effective temperature reduction on the street, track, or drag strip
Increased fluid capacity for improved heat dissipation
Efficient temperature regulation for both stock and modified vehicles
Includes Magnetic Drain Plug to capture any metallic debris/fragments in your cooling system
Includes 19 PSI High-Pressure Radiator Cap which effectively raises the boiling point of engine coolant, providing a safer and more efficient system
Mishimoto Lifetime Warranty
Install Difficulty: 3
Give some extra cooling power to the V8 under the hood of your 2008-2009 Pontiac G8 with this Mishimoto Performance Aluminum Radiator. Our radiator replaces the stock thin core and plastic end tanks with a 2.2 inch-thick core and fully TIG-welded aluminum construction for maximum durability. Our custom-engineered, two-row core provides all the cooling your 6.0L V8 needs for everyday commuting, thrashing some back roads, or a day at the track. The Mishimoto 2008-2009 Pontiac GTO Performance Aluminum Radiator is available in a polished finish and provides optimal cooling for both manual and automatic vehicles. This radiator also includes the Mishimoto Lifetime Warranty for a lifetime of worry-free cooling.
