TechSpec Overall Height (in): 27.87
TechSpec Overall Length (in): 27.08
TechSpec Overall Width (ins): 3.34
TechSpec Core Length (in): 27.08
TechSpec Core Height (in): 23.22
TechSpec Rows: 2
TechSpec Inlet (in): 1.41
TechSpec Outlet (in): 1.41
TechSpec Core Thickness (in): 1.96
TechSpec DPI: 2691
TechSpec Material: Aluminum
TechSpec Applications: Infiniti QX56 V8 (5.6) 2004-2013--Nissan Armada V8 (5.6) 2005-2014--Nissan Titan V8 (5.6) 2004-2014
TechSpec Engine Codes: VK56
TechSpec Chassis Codes: A60
Note: Radiator Cap Not Included With Purchase--Our performance aluminum radiator is designed to function with the OEM radiator cap. Using an aftermarket radiator cap is not recommended and may result in cooling system failure.--
TechSpec Includes: Mishimoto Aluminum Radiator w/ Internal Transmission Cooler-- Mishimoto Magnetic Drain Plug--Mishimoto Lifetime Warranty
Features:Direct fit for 2004-2014 Nissan Titan
37-percent increase in core volume over stock for improved cooling capacity
2-row core is 38-percent thicker than stock for improved heat transfer
Internal transmission cooler effectively reduces transmission fluid temps
CNC-machined transmission cooler fittings prevent mixing of coolant and trans fluid
Precision TIG-welded aluminum end tanks won't crack like stock plastic tanks
Magnetic drain plug captures ferrous debris, preventing it from clogging cooling system
Mishimoto Lifetime Warranty
Install Difficulty: 3
Nissan has a legacy for building high-performance tuner icons like the Skyline and Z-cars, but with the introduction of the Titan in 2004, Nissan threw its hat into the full-size pickup ring. Powered by the 5.6L VK56 V8, the Titan quickly developed a reputation for being a reliable workhorse that could easily keep up with the likes of Ford and Chevy. But, after almost two decades of life as a work truck, or just daily driving, even the most reliable truck is going to show its age and require some maintenance. Your Titan's cooling system is essential to maintaining its reliability, but after thousands of heating and cooling cycles, your radiator has probably seen better days. The stock Titan radiator's plastic end tanks are prone to becoming brittle over time, leading to leaks that can leave you stranded on the job site or side of the road. Even worse, the fragile in-tank transmission cooler can crack at the fittings, leading to coolant in your transmission fluid and catastrophic transmission failure. Mishimoto has created an all-aluminum performance radiator for your 2004-2010 Nissan Titan to prevent these issues and give the Titan a boost in cooling performance. Our radiator features a 2-row core that's 38% thicker than stock with a 37% increase in core volume for improved heat transfer and cooling capacity. The end tanks of the Mishimoto radiator are made from aircraft-grade aluminum that's precision TIG-welded for maximum durability and pressure tolerance. We've also CNC-machined the transmission cooler fittings and made them integral to the lower tank to ensure they never loosen or break, protecting your transmission. Like all Mishimoto radiators, this 2004-2010 Nissan Titan performance aluminum radiator carries our Mishimoto Lifetime Warranty for a lifetime of reliability.
