Features:Direct fit for Ford E4OD/4R100/5R110 transmissions
Durable cast-aluminum construction for long-lasting performance
Increases fluid capacity by 6.6 quarts over the stock transmission pan for more cooling capacity
Bolt retainers hold fasteners in place for easy installation
Internal baffles reduce sloshing and enhance heat dissipation for smoother, more efficient transmission operation
1/8-inch NPT port makes adding a temp sensor fast and easy
Precision-machined sealing surface helps prevent leaks
Magnetic drain plug makes servicing your transmission a breeze
Gunmetal gray powder coat finish adds style and function to your truck’s undercarriage
Mishimoto Lifetime Warranty
TechSpec Installation Notes: Drain Plug Torque Spec: 15 lb-ft----A pan gasket is not included with this product. Mishimoto recommends replacing it with OEM Part #F6TZ-7A191-A to ensure leak-free operation.
TechSpec Includes: (1) Cast Aluminum Transmission Pan--(1) Magnetic Drain Plug--(20) Silicone Bolt Retainers--(20) Socket Head Cap Screws w/ Washers--(1) 1/8-in NPT Plug--Mishimoto Lifetime Warranty
TechSpec Applications: 1989-2010 Ford 7.3L, 6.0L, 6.4L Powerstroke E4OD 4R100 5R110
TechSpec Fluid Capacity (qts): 6.64 (Pan)/ 13.64 (Total E4OD/4R100)/ 12 (Total 5R110)
Install Difficulty: 1
This Mishimoto Aluminum Transmission Pan is a direct-fit, high-performance upgrade for your 1989-2010 Ford 7.3L, 6.0L and 6.4L Powerstroke. Cast from high-quality aluminum and powder coated Gunmetal Gray, our transmission pan is a robust and long-lasting upgrade for your vehicle's transmission. With a sleek design and bottom ribs, this pan not only adds to the overall aesthetic of your truck but also provides improved cooling performance.----This transmission pan features internal baffles that reduce sloshing and enhance heat dissipation, resulting in smoother transmission performance. Our casting features a precision-machined sealing surface, ready to accept either a factory-style gasket or sealant of your choice (not included). Additionally, the Mishimoto 1989-2010 Ford Powerstroke Aluminum Transmission Pan adds an extra 6.6 quarts of ATF to help maintain optimal transmission operation.----Fed up with the frustration of trying to hold up a transmission pan with one hand while threading the fasteners in with the other? Mishimoto has you covered with pre-installed bolt retainers that hold the fasteners in the pan, allowing you to easily thread the bolts without dropping them on the ground, your head, or worse, that pan of nasty transmission fluid you just drained. Additionally, our pan comes equipped with a magnetic drain plug for easy draining and a 1/8-inch NPT port and plug for temperature sensors to make servicing your transmission and monitoring temperatures a breeze.----This direct-fit upgrade offers affordable durability and helps maintain smooth transmission operation, ensuring a long life for your transmission. Like all Mishimoto products, this transmission pan is backed by the Mishimoto Lifetime Warranty.
