TechSpec Overall Height (in): 29.9
TechSpec Overall Length (in): 29.9
TechSpec Overall Width (ins): 4.5
TechSpec Core Length (in): 29.87
TechSpec Core Height (in): 23.54
TechSpec Fluid Capacity (gal): 6.51
TechSpec Rows: 2
TechSpec Inlet (in): 1.77
TechSpec Outlet (in): 1.77
TechSpec Core Thickness (in): 2.28
TechSpec Drain Plug Thread Size: M12 x 1.5
TechSpec DPI: 1725
TechSpec Material: Aluminum
TechSpec Applications: 1995-1997 F250--1995-1997 F350
Note: Model Year 1995 Fors F-250s produced prior to 1/31/1995 use the 1994 model year radiator: 1983-1994 Ford 6.9L & 7.3L IDI Diesel Performance Aluminum Radiator
TechSpec Includes: Mishimoto Radiator--Magnetic Drain Plug--1/8-inch NPT Plug--Mishimoto Lifetime Warranty
Features:Direct fit for 1995-1997 OBS Ford trucks equipped with the 7.3L Powerstroke
Full aluminum construction with durable, TIG-welded end tanks
Features a two-row, 2.28-in thick brazed aluminum core, providing ideal fluid temperatures during all driving conditions
Increased fluid capacity and superior heat dissipation
Perfect upgrade to the stock plastic end tank radiator
Ideal for trucks transporting heavy loads, towing, and/or driving in extreme environments
Includes Magnetic Drain
Plug to capture any metallic debris/fragments in your cooling system
Mishimoto Lifetime Warranty
Install Difficulty: 3
The 7.3 Powerstroke is well known for its reliability and longevity, so why not pair an amazing engine with a radiator that can keep up! Mishimoto has released a performance aluminum radiator for the 1995-1997 Ford 7.3L Powerstroke.The Mishimoto Powerstroke aluminum radiator is an ideal upgrade for your work truck, mud truck, or modified pull truck.Whatever the use of your truck, the Mishimoto radiator will keep your engine cool with its brazed aluminum core and TIG-welded end tanks for superior reliability and performance.The Mishimoto 7.3L radiator is precision engineered for exact factory fitment it bolts right up to the stock fan shroud, allowing for easy installation.Included with the Mishimoto Powerstroke aluminum radiator is our magnetic drain plug and signature lifetime warranty.
