Specifications:
Manufacturer: Defi
Part Number: DF17701
Compatible Informations : Oil Pressure,Oil Temperature,Water Temperature,Voltage,RPM,Vacuum,Exhaust Gas Temperature,Boost
Type: Advance System
Comunication: Analog
Defi-Link ADVANCE Control Unit SE is a product necessary to operate the advanced system meters and displays. All settings and operations of the ADVANCE system are performed with this ADVANCE Control Unit SE.
Adoption of advanced system (two-way communication)
Click here for a detailed explanation of the advanced system
Defi-Link Meter ADVANCE A1, BF, RS, FD, etc. Centralized operation of up to 7 ADVANCE series meters and displays
Adding the second and subsequent meters is only for connecting the meters and wiring from the sensor to the advanced control unit.
* Meters with the same display (model) cannot be connected at the same time. (Example: Connecting two turbo meters, etc.)
Remote control switch with night light (white) enables hand operation
Automatic adjustment of meter lighting by linking ADVANCE FD/ZD Directed by the opening ceremony and ending ceremony that can be selected from 2 types The self-diagnosis function diagnoses disconnection, short circuits, and communication errors, and notifies you with a warning display. Any warning value can be set, and a buzzer sounds in synchronization with the warning display (buzzer sound can be set to ON/OFF) Differential pressure can be displayed on the fuel pressure gauge or ADVANCE FD/ZD by connecting the fuel pressure sensor and turbo sensor.
