Defi-Link Meter ADVANCE BF is a series of gauges that require connection to the Defi-Link ADVANCE Control Unit (DF07703). These electronic blacked-out gauges boast high response and a refined design. While the car is off, they feature a sleek black face without numbers. Once the car is turned on, the gauges instantly light up, showcasing their full effect.
Specifications:
Manufacturer: Defi
Part Number: DF09901
Information Displayed: Boost
Type: Advance System
Comunication: Analog
Dimension: 60mm
Illumination Colour: White
Reading limitation : -100kPa to +200kPa
Unit: Metric
Main Features:
-Stepping motor: STS26/VS2
-Illumination color: white/amber red/blue (in USDM models, only amber red is available)
-Illumination ON/OFF: interlocked with vehicle illumination switch
-LED illumination
-Indicator output
-Built-in indicators
-Driving data can be recorded & replayed
-Opening mode/Ending mode
-Size: 60mm/80mm tachometer
-Applicable number of cylinders: 1, 2, 3, 4, 5, 6, and 8
Included in this kit will be:
-Gauge 1pc
-Sensor 1pc
-Sensor wire (8 1/5ft) 1pc
-Power supply wire (3 1/3ft) 1pc
-Meter cup 1pc
-Regular position bezel 1pc
-Double sided tape 1pc
-Buffer 1pc
-Mounting bracket 1pc
-Hardware
